I-beam

●According to GB/T26079-2010.
●Function and characteristic: adjust the position of the hook per the dimensions of the loads.
●The data in the table are finalized product data.
●The lifting beam can be designed according to the requirements of the customer.

ITEM No.	WLL	Dimensions(mm)							Self weight
ITEM No.	t	L1	L2	A	B	C	R	长×宽×高	Kg
HLC-2T	2	3	1-2	1450	220	800	100	3130×2080×1450	280
HLC-3.2T	3.2	3	1-2	1480	220	835	100	3130×2080×1480	288
HLC-5T	5	3	1-2	1500	220	835	100	3130×2080×1500	290
HLC-8T	8	3	1-2	3500	385	2500	100	3180×2240×3500	1045
HLC-10T	10	3	1-2	3600	445	2500	120	3180×2240×3600	1145
HLC-12.5T	12.5	3	1-2	3700	445	2500	120	3180×2240×3700	1195
HLC-16T	16	3	1-2	3750	450	2500	120	3180×2240×3750	1295
HLC-20T	20	4	1-2	3800	565	2500	125	4200×2240×3800	1875
HLC-25T	25	4	1-2	4000	650	2500	155	4200×2240×4000	2155
HLC-32T	32	4	1-2	4100	650	2500	155	4220×2240×4100	2325
HLC-40T	40	4	1-2	4100	650	2500	155	4250×2240×4100	2740
